5Port Quick ethernet Change Module PCBA Hub mini measurement 88*44.5MM transmission fee 10/100Mbps capability 1G cheep worth free specific

SKU: OWQSOKCK5QH0 Category: Network Switches

$5.90

Definition

PL-ES2105DI-F2 5Port POE Change Enter energy 5V1A

mini measurement 5 port 10/100mbps RJ45 quick ethernet change module

Easy function:

5 10/100mbps RJ45

85*44.5*20mm measurement

mini measurement,plug n play

Indicators for energy,hyperlink/act


Options

Complies with IEEE 802.3 and IEEE 802.3u requirements

5port10/100Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX

Assist IEEE 802.3x circulation management for full duplex mode and backpressure for half duplex mode on all port

Non-blocking switching structure that ahead and filter packets at wire-speed for max throughput

Assist MAC tackle auto-learning and auto-aging

LED indicators for monitoring energy,hyperlink/exercise

Requirements cabling measurement design,PCBA measurement: 85×444.5x20mm

Energy enter DC vary 5

supported OEM



Product specification

Requirements

IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Quick Ethernet

IEEE 802.3x circulation management

protocol

CSMA/CD

Transmission Price

Ethernet 10Mbps (half duplex),20Mbps (full duplex); 10BASE-T:14,880pps/port
Quick Ethernet 100Mbps (half duplex),200Mbps (full duplex); 100BASE-TX :148800pps/port

Topology

Star

Community Medium

10Base-T:Cat 3 or above Cat.3 UTP(Lower than 100m)

100Base-TX:Cat 5 UTP(Much less than100m)

Variety of Ports

5port 10/100M RJ45 ports

UPLINK

Any port (assist Auto-MDI/MDIX operate)

Transmits Technique

Retailer-and-Ahead

Temperature

Working Temperature 0 ~40 Celsius (32 F~104 F)

Storage Temperature -40 ~70 Celsius (-40 F~158 F)

Humidity

Working Humidity 10 ~90 p.c non-condensing

Storage humidity 5 ~95 p.c non-condensing

Change capability

1G

LED Indications

1* energy LED(Energy: Inexperienced)

5pcs LEDs(Hyperlink/Act: Inexperienced)

Energy Provide

DC Enter 5V

Packing Content material:

1 * 5 Ethernet Change Module

Specification: 5Port Quick ethernet Change Module PCBA Hub mini measurement 88*44.5MM transmission fee 10/100Mbps capability 1G cheep worth free specific

Brand Name

XTDP-Link

Certification

NONE, CE ROHS

Origin

CN(Origin)

Function

POE, Stackable

Transmission Rate

10/100Mbps

Number of Interfaces

7

Switch Type

SOHO

Package

Yes

Communication Mode

Full-Duplex & Half-Duplex

Model Number

PL-PSE2105DI-F1

Switch Capacity

1G

DC Input

12V 15V 18V

Passive POE Switch

Yes

Supply Power

45/+ 78/-

PCBA Size

88*54.5MM

POE Number Port

4 Ports

Data Number Ports

5 Ports

LED Display

One Power and 5 data LED

Support IEEE802.3af/at

no

Port POWER

5 Watt
