4 PON port mini ftth fiber optic 4 SFP port PX20+ PX20++ PX20+++ 4 pon port 4 SFP slots epon OLT 10/100/1000Mauto-negotiable
$503.10
E04L 4 PON port mini ftth fiber optic 4 pon port epon olt
The E04L sequence is a excessive built-in, medium capability field ERON OLT switching tools developed by Hongsheng Guang Shenzhen for the operator entry and enterprise park community. The product follows IEEE802.3ah technical commonplace and meets the necessities of EPON OLT tools in “YD/T 1475-2006 entry community technical necessities”. It has good openness, massive capability, excessive reliability and full software program features. It’s broadly used within the development of community protection, particular community development, enterprise community park entry and different entry community development.
Benefit:
EPON:OLT follows the technical commonplace of IEEE802.3ah and China telecom. (YD/T 1475-2006)
l Capability: Every PON helps as much as 64 terminals, the entire gadget helps as much as 256 ONUs beneath full configuration.
l Uplink: assist electrical and optical modules, will be flexibly configured based on completely different networking.
l Dimension: 1U cassette save area, low energy consumption and save value.
l Optical Line Safety: assist mechanically change when the road is debug.
l Excessive reliability: helps twin energy provide(Default single energy provide).
Product Description
|
Mannequin |
E04L |
|
|
DDR |
512M |
|
|
FLASH |
16M |
|
|
Dimension (L*W*H) |
Product measurement:442mm×260mm×44mm :520mm×372mm×87mm |
|
|
Weight |
||
|
Uplink |
QTY |
8 |
|
Copper |
4*10/100/1000Mauto-negotiable,RJ45 |
|
|
SFP |
4 SFP slots |
|
|
PON |
QTY |
4 |
|
PhysicalInterface |
4 SFP slots |
|
|
Connector Kind |
1000BASE-PX20+/PX20++/PX20+++ |
|
|
Max splitting ratio |
1:64 |
|
|
Administration Ports |
CONSOLE port/NMS PORT |
|
|
Energy Enter |
AC: 100V~240V AC 47/63Hz |
|
|
Help commonplace |
IEEE 802.3ah EPON IEEE802.3(10Base-T) IEEE802.3u(100Base-TX) IEEE802.3z(1000BASE-X) IEEE802.3ab(1000Base-T) IEEE802.1Q(VLAN) IEEEE802.1d(STP) IEEEE802.1W(RSTP) IEEE802.1p(COS) IEEE802.1x(Port Management) IEEE802.3x(flow-control) Every OLT interface helps at most 64 ONU; Transmission distance of every OLT is at most 20Km |
|
|
PON operate |
Help auto register and ensure Blacklist and whitelist onu DBA configure P2P ONU authorization |
|
|
Layer 2/3 operate |
VLAN,QinQ,hyperlink convergency, broadcast strom management Help at most 4094 VLAN;efficiency statistic 16K MAC deal with;mac deal with administration Port mirror / Static Trunk Help RSTP Storm management Help IGMP Snooping/proxy Help 512 router hosts Help 64 router subnets Restrict amount of most person at every port Port isolation Packe storm management ACL entry management based mostly on information stream QoS based mostly on port, VID, TOS and MAC deal with; Encrytion of PON port transmitting information Help 802.1X authentication |
|
|
Configuration and Administration |
SNMP/NMS WebGUI administration CLI, SNMP, TELNET,cluster and so on. SSHv1/v2 Software program and bootrom improve by TFTP and FTP Native server syslog to document system log Chinese language/English command immediate Ping and traceroute Debug/Log administration Consumer administration; Alarm administration. |
|
|
Lightning |
Service port has lightning safety |
|
|
Upkeep |
Telnet distant upkeep |
|
|
Temperature |
-10℃~60℃ |
|
|
Humidity |
5%~95% |
|
Firm Data
Packaging & Transport
Specification: 4 PON port mini ftth fiber optic 4 SFP port PX20+ PX20++ PX20+++ 4 pon port 4 SFP slots epon OLT 10/100/1000Mauto-negotiable
|
