Wendry 3.5″ Floppy Drive Emulator, 1.44MB USB Flash Disk Floppy Drive, 34-Pin Floppy Disk Driver Interface Appropriate for Yamaha Korg Roland Electrical Organ with 720KB Floppy Drive

Value: $45.80
(as of Jul 10,2022 13:37:49 UTC – Particulars)

Floppy Driver:
Interface: 34 pin floppy driver interface, 5V DC 4 pin energy plug
Format of disk: Cylinders: 80 Tracks: 160 Sectors/Monitor: 9 Bytes/Sector: 512 Information
Switch price: 500 kbps
Encoding methodology: MFM
Panel:
8 phase numbers: Symbolize partitions quantity
Inexperienced LED: Standing of learn and write operation
USB port: Join USB flash drive
Button:
When no USB flash drive plugged on emulator:
Left button used to rise ten-digit, proper button used to rise single-digit, press 2 button collectively to rise hundred-digit, when the hundred-digit is ‘b’, the picture mode used.
When an USB flash drive plugged on emulator:
Left button used to switch knowledge from built-in reminiscence into USB flash drive, proper button used to switch knowledge from USB flash drive into built-in reminiscence.
Firmware model of emulator:
Hold pressed 2 button collectively, energy on, 8 phase numbers will show firmware model and knowledge of emulator to detect completely different mannequin.
Error Code:
E0: No specified file in USB flash drive
E16: Constructed-in reminiscence fault
Jumper Setting:
J5: —
JA: Set to generate READY sign on 34pin of floppy driver interface
JC: —
JB: —
S0: Driver choose 0
S1: Driver choose 1
MO: Motor

Specs:
Mannequin: SFRM72-FU-DL
Compatibility: Appropriate for Yamaha Korg Roland Electrical Organ with 720KB floppy drive
Voltage: 5V DC
Interface: USB port, 4 pin energy plug, 34 pin plug
Housing materials: ABS
Measurement (L x W x H): Approx. 122 x 102 x 25mm / 4.8 x 4.0 x 1.0inch
Coloration: Grey (Proven as the image)
Bundle weight: 98g

Bundle Included:
1 x USB Emulator

Use regular USB flash drive because the medium for switch design.
34pin floppy driver interface, 5V DC energy provide, straightforward to put in.
720KB built-in flash reminiscence, with FAT12 format, used for cache knowledge from USB flash drive.
720KB capability of information in root listing or 999 folders may be searched.
Lengthy file identify and 4-level listing in 999 folders supported.
